SLASH+ 3D Printer
Equipped with the world's fastest 3D printer technology
-
Ultra-high resolution, ultra-fast, liquid crystal display (LCD) contact photocuring 3D printer
-
To enable high-quality 3D printing without sacrificing speed and ease of use. SLASH is developed with the same precision and speed as industrial 3D printers, while taking into account the price acceptable to ordinary consumers
-
With easy-to-use software, the slicing software has a variety of basic functions and the cloud for sharing and publishing creations, making it no longer difficult to have high-precision 3D printing
Product Analysis
Why
need
In the past, it was necessary to use large-scale industrial printing machines to achieve the printing speed, but now the SLASH+ 3D desktop printer can print high-precision 3D models at a fraction of the cost and speed of industrial grades; the printing time is reduced The solidification time increases the printing speed, so that students can quickly print out the model products needed in the classroom in the classroom.
Reduce curing time and increase printing speed when printing
product
Advantage
High-quality industrial-grade 3D models can be printed conveniently at any time
-
The desktop 3D printer developed with the same precision and speed as the industrial 3D printer can conveniently print high-quality industrial-grade 3D models at any time.
-
Files can be transferred via Wi-Fi, making printing files more convenient.
-
When the model is printed, this printer reduces the time for solidifying the 3D model volume, increases the output speed, and reduces the waiting time for printing.
-
The machine has built-in advanced model repair function and surface smoothing technology to make the printed model more detailed.
Competition
Advantages
A 3D printer that can print at high speed and achieve industrial-grade model accuracy and details
-
Compared with commercially available desktop 3D printing machines, the SLASH+ 3D printer is a 3D printing machine that can print at high speed and achieve industrial-grade model accuracy and details.
-
Large solid objects can be printed at high speeds, faster than most other desktop 3D printers.
application
situation
Use the SLASH+ 3D printer to accurately and quickly print out the industrial-grade required part models
For example, students of mechanical and information science can use this 3D printer to accurately and quickly print out industrial-grade part models, so when students find design errors, they can correct and reprint the proof.
Product Description
-
SLASH+ 3D printer
Reduce cure time to increase speed
Before SLASH, 1,000 cc/hr was only possible on large industrial machines worth over $100,000, now we make it possible to use it in your home.
High resolution at low cost
-
With WQXGA (2560 x 1600, 339 ppi, 75μm x-y axis) ultra-high resolution IPS LCD display and ball screw (10μm z axis), SLASH is able to deliver industrial-grade precision and detail.
-
As an example, a WQXGA DMD chip (used in a DLP projector) alone will cost you over $3500****. Adding image-correcting optics and other components to a DLP 3D printer system using this chip is bound to be very expensive. On the other hand, with LCD contact exposure technology, SLASH can provide the same results much faster and at a fraction of the cost.
product specification
SLASH+ 3D printer
printing technology
LCD light curing
print size
192 × 120 × 200mm
XY resolution
75µm, WQXGA [2560 × 1600]
highest precision
±20 µm
Layer thickness｜Z axis
10,25,50,100,150,200,300µm (can be customized)
separation technology
Polymer membrane separation technology (about 100 times more durable than PDMS)
support
UNIZ smart support generation technology
print speed
1,000 cc/hour, 200 mm/hour (thin wall structure)
Resin level control
automatic level control
size and weight
350×400×530mm [W×H×D] , 14KG
operating temperature
Resin temperature must be 18-28°C
Power Requirements
100-240V,3A 50/60Hz,240W
optical system
5000K Lux blue LED array Refractive index matching liquid cooling system
mechanical structure
Carbon Fiber Reinforced/Steel Reinforced, Adjustable Tray
Link method
USB, Wifi, Ethernet
System Requirements
Windows 7 SP1 and above
Mac OS X 10.7 or later (64-bit only), 16GB RAM, OpenGL 2.1, dedicated video card
Multiple printers can be managed
Large file support (1GB+)
Features
Built-in advanced model repair function Surface smoothing technology
Applicable format
.STL,OBJ,AMF,3MF,UNIZ
